The low-headroom bridge crane is specifically designed for operational environments with limited space and low clearance heights. Its compact design and low profile reduce the overall height and footprint of the crane, ensuring efficient operation within confined spaces. The low-headroom bridge crane offers customizable configurations to meet the varying architectural layouts and operational requirements of low-clearance environments. Its sleek vertical design enhances operational flexibility, enabling smooth operations within tight spaces while maximizing floor space utilization. This low-headroom bridge crane is ideally suited for industries such as construction, manufacturing, and warehousing.
Capacity(t) | Span(m) | Lifting height(m) | Lifting speed(m/min) | Power Supply Voltage | Work class |
1ton | 7.5-22.5 | 6-30 | 8 or 8/0.8 | 220V-660V, 50-60Hz, 3ph AC | A3-A5 |
3ton | 7.5-31.5 | 6-30 | 8 or 8/0.8 | 220V-660V, 50-60Hz, 3ph AC | A3-A5 |
5ton | 7.5-31.5 | 6-30 | 8 or 8/0.8 | 220V-660V, 50-60Hz, 3ph AC | A3-A5 |
10ton | 7.5-31.5 | 6-30 | 7 or 7/0.7 | 220V-660V, 50-60Hz, 3ph AC | A3-A5 |
20ton | 7.5-31.5 | 6-30 | 3.5 or 3.5/0.35 | 220V-660V, 50-60Hz, 3ph AC | A3-A5 |
